Cheap Portable High Accuracy Windows USB Dual Camera Binocular Biometric IRIS Scanner for Election

Product Name: Cheap Portable High Accuracy Windows USB Dual Camera Binocular Biometric  IRIS Scanner for Election model SF-01S



Main Features:



Dual Optic Camera： Dual 5.0M pixel cameras with dual processing CPU; IPD distance  38mm to 80mm
Pixel Resolution:  507ppi.
Iris Image Pixel: 640*480 or 1280*1024 for option
Spatial Resolution: Contrast Transfer Function 76% at 2 cycles/mm
Illumination : 780 or 800 rem
Capture size :  20mm x 15mmx 10mm
Iris Scan Range: 13cm－18cm
Authentication Rate : FAR<0.000012%、FRR<0.01%
Ambient light intensity:  0－1000Lux
Connectivity: USB 2.0 High Speed
 Registration Time : less than 2s
Authentication time: less than 30ms



Functional Display

SF-01S is using dual 5.0M pixel cameras adapting International advanced iris recognition algorithm, faster and more accurate in recognition according to ISO/IEC19794-6:2005

SFT Windows USB Binocular IRIS Scanner is with cheap price and ergonomic design for more convenient usage and comfortable mirror positioning guide.

Detailed Technical:

Dual Optic Camera： Dual 5.0M pixel cameras with dual processing CPU; IPD distance  38mm to 80mm
Pixel Resolution:  507ppi.
Iris Image Pixel: 640*480 or 1280*1024 for option
Spatial Resolution: Contrast Transfer Function 76% at 2 cycles/mm
Illumination : 780 or 800 rem
Capture size :  20mm x 15mmx 10mm
Iris Scan Range: 13cm－18cm
Authenticataion Rate : FAR<0.000012%、FRR<0.01%
Ambient light intensity:  0－1000Lux
Connectivity: USB 2.0 High Speed
 Registration Time : less than 2s
Authentication time: less than 30ms
Cable Length: 1.8meters or 3meters for option
Weight: 0.8KGS
Images per second (Bitmap): 8
Operating Indicator: Voice guide and optical guide
Housing: Fixed distance between iris and camera.
Handling: ISTA 2A Shipping and Handling Specification. (Shock & Vibration)
Capture Methodology: Device should be capable of auto-capturing iris. Anti-dilation of the pupil should be used to accommodate smaller pupil capture. Should also have image finding and stabilization, pupil segmentation and image quality assessment for quick and easy image collection.
Image format: ANSI INCUS 379-2004 Or ISO/IEC 197946 standards
Eye-Safety: Class I LED Product IEC 60825-1:1993+AI: I997-HA2:200I ANSI RP:27.I-96 or Class I LED Product IEC 62471
Operating temperature: －20－68℃
Voltage : DC 5V, Peak current less than 400mA
Working Humidity: 0－85%
IP Rating: IP54
Product Size : 200mm*60mm*90mm
Packing size : 243mm*204mm*103mm
Certifications: CE, OR UL, RoHS, FCC
SDK: SDK compatibility should be with- windows operating system
Warranty: 1 Year full warranty
